Socket management and immediate implant placement

Fractured molar – an immediate transition

Dr. Peter Hunt · United States
 · July 21, 2023

BioBrief - Extraction Socket Management

The Situation

The case here is typical enough, a failing mandibular molar with a vertical sub-osseous fracture. Traditionally, the replacement process can take three or more surgical exposures (extraction and regeneration), (implant placement), (second stage exposure) and more than a year of therapy.


The Approach

Immediate molar replacement requires atraumatic removal of the fractured tooth, careful socket debridement and development of a channel for an ideally positioned implant. The implant then needs to be placed down in the bone channel with the implant platform positioned just below the socket walls. It needs to be stable. Channel deficiency augmentation is achieved with Geistlich Bio-Oss Collagen® which is covered with a collagen matrix, Geistlich Mucograft® with the edges tucked under the gingival margins and sealed over with tissue glue.


The Outcome
This single stage replacement protocol has proven to be simple, safe and highly effective providing the socket is fully degranulated and the implant is stable and not loaded in the early healing stages. It works well when a gingiva former
is immediately placed into the implant instead of a cover screw, Geistlich Bio-Oss Collagen® is packed around the implant to fill the residual socket, then covered with a Geistlich Mucograft® and sutured. There is no need for flap advancement to cover over the socket.


Keys to Success

Atraumatic extraction
Thorough degranulation and debridement of the residual socket
Adequate stability for the implant
Placement of the implant platform down just below the walls of the socket
Placing a 4.0 mm height gingiva former instead of a cover screw
Augmenting with Geistlich Bio-Oss Collagen® and covering with Geistlich Mucograft®
No loading of the implant in the early healing stages

About the author

Dr. Peter Hunt | United States

Peter Hunt, BDS, Msc, LDSRCS Eng • Philadelphia, PA
Periodontist - University of Pennsylvania
After graduate training on an Annenberg Fellowship at the University of Pennsylvania, Dr. Hunt helped start up the University of the Western Cape Dental School in Cape Town, South Africa. He returned to the University of Pennsylvania where in time he became Clinical Professor of Periodontics. Later he helped start up Nova Southeastern‘s Dental School where he was Professor of Restorative Dentistry, Post Graduate Director and Director of Implantology. He has had a private practice in Philadelphia focusing on implant and rehabilitation dentistry since 1981.
